Scientific Precision · Thermal Engineering

Rigid
Foam
Systems

20 s
Density
350 cps
Viscosity
26 kg/m³
Free Rise Density

High-density polyurethane foam systems for thermal insulation, structural panels, and cold storage. Engineered at the cellular level for precision performance.

Explore the System Download Product TDS
High-Density Rigid Foam Systems Thermal Insulation Solutions Cold Storage Foam Technology Closed Cell PU Foam Systems Fast Expansion Foam Formulation Structural Insulation Panels Low Thermal Conductivity Performance Atlas Rigid Foam Technology Industrial Insulation Applications Energy Efficient Foam Systems High Compression Strength Foam PU Foam for Refrigeration Industry Precision Density Control Systems Advanced Polyurethane Foam Solutions Thermal Barrier Insulation Technology High-Density Rigid Foam Systems Thermal Insulation Solutions Cold Storage Foam Technology Closed Cell PU Foam Systems Fast Expansion Foam Formulation Structural Insulation Panels Low Thermal Conductivity Performance Atlas Rigid Foam Technology Industrial Insulation Applications Energy Efficient Foam Systems High Compression Strength Foam PU Foam for Refrigeration Industry Precision Density Control Systems Advanced Polyurethane Foam Solutions Thermal Barrier Insulation Technology
Expansion Dynamics

Liquid to Solid in Seconds

Two-component Atlas PU rigid foam system reacts on mixing — forming a closed-cell structure with excellent insulation and strength. Designed for thermal applications, it expands and fills cavities uniformly with minimal voids.

20 ± 2s
CREAM TIME
100 : 130
MIXING RATIO
≥90%
CLOSED CELL
26 ± 2
FREE RISE DENSITY
MOLD CAVITY
0%
Drag to simulate expansion Mix — 0s
0s Mix15s Cream60s Rise120s Set
Thermal Performance

Thermal Barrier Map

Adjust the external temperature to see how Atlas Rigid Foam maintains stable internal conditions. Thermal conductivity: 0.022 W/mK — among the lowest for rigid foam insulation.

External Temperature -20°C
-40°C Arctic+60°C Industrial
ΔT: 72°C
Temperature differential maintained by 75mm Atlas Rigid Foam panel
-20°C
OUTSIDE
+5°C
INSIDE · STABLE
Cold Storage
0.022
W/mK λ Value
≥95%
Closed Cell
<1%
Water Absorption
Engineering Tool

Density
Calculator

Enter your project dimensions and target density. Get exact component quantities, mixing ratios, and expected cure profile for the Atlas Rigid Foam system.

400 kg
Total Material Required
1.0 : 1.0
A:B Mix Ratio (by weight)
24h
Full Cure at Temperature
Estimates only — contact our team for certified project specs. Get Certified Specs →
Applications

Industrial
Applications

Technical Data

System
Specifications

S. No Properties Result
1ComponentTwo Component
2ColourClear Yellow Liquid
3Density1.12 Kgs
4Viscosity350 Cps
5Cream Time20 ± 2
6Gel Time135 ± 10
7Tack Free Time175 ± 10
8Free Rise Density26 ± 2
9Mixing Ratio100 Parts of Resin / 130 Parts of Iso
10Application Temperature10°C - 30°C
11Packaging210 Kgs / 250 Kgs
Download Full TDS

Calculate Your Density

Get precise material quantities, mixing ratios, and certified system specs from our foam engineering team.

Request Consultation → ↓ Download TDS
